[JSP] MVC PATTERN



모델1 : JSP 페이지에서 화면을 보여주고 요청을 하게 되면 J네 페이지에서 직접 모델에 접근하여 처리

- 데이터 베이스 연동하는 JSP 페이지를 만들 때 디자인 부분과 데이터 베이스와 연동하는 로직 부분이 모두 같은 페이지에 코딩



모델2 : 디자인 부분과 로직 부분을 나누어서 개발하기 때문에, 디자이너는 디자인 부분만, 프로그래머는 로직 부분만 개발 가능

- 독립적 (디자이너는 JSP페이지, 프로그래머는 JAVA 클래스)





MVC : Model, View, Controller

- Model : 데이터 베이스와 연동하는 부분등의 로직 부분

- View : 화면 출력

- Controller : 위 두 부분을 적절하게 연결시켜주는 역할



#모델2는 Model과 View를 독립적으로 코디하기 때문에 Controller를 만들어서 Model과 View 사이에 개입하여 서로 연동하는 역할





Model : JavaBean

- MVC에서 실제로 비즈니스 로직 처리

- 비즈니스 로직을 처리하여 결과를 Controller를 통해 View 페이지로 전달

- 데이터 베이스 부분을 모델에서 구현

- 처리가 완료되면 결과를 Controller를 통해서 View로 전달하여 처리된 내용이 화면에 표시

- 클래스 파일로 이루어져있음

- 실제로 모델 클래스의 비즈니스 로직을 가져다가 쓰는 곳은 Controller와 Model 사이에 존재하는 Command 클래스





View : JSP

- MVC 패턴 중 화면 출력 부분

- 화면 출력 담당으로 JSP 페이지로 구성

- 절대로 데이터 베이스 연동과 같은 비즈니스 로직을 구현하지 않음





Controller : 서블릿

- 요청을 받아서 요청에 해당하는 Model과 View를 호출하는 역할만 하기 때문에 View처럼 JSP 페이지로 구현

- 보여지는 페이지가 아닌 연결시켜주는 통로 역할만 함

- MVC패턴에서 중심역할을 한다는것과 반드시 서블릿으로 이루어짐





---





설정



파일 종류 및 위치









- XML 파일



web.xml

<?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xmlns="http://xmlns.jcp.org/xml/ns/javaee"
    xsi:schemaLocation="http://xmlns.jcp.org/xml/ns/javaee http://xmlns.jcp.org/xml/ns/javaee/web-app_3_1.xsd"
    version="3.1">
    <display-name>0502</display-name>
    <welcome-file-list>
        <welcome-file>index.html</welcome-file>
        <welcome-file>index.htm</welcome-file>
        <welcome-file>index.jsp</welcome-file>
        <welcome-file>default.html</welcome-file>
        <welcome-file>default.htm</welcome-file>
        <welcome-file>default.jsp</welcome-file>
    </welcome-file-list>
    <!-- Servlet 맵핑 -->
    <servlet>
        <servlet-name>BoardFrontController</servlet-name>
        <servlet-class>net.board.action.BoardFrontController</servlet-class>
    </servlet>
    <!-- 파일이 .bo일 때 BoardFrontController로 간다 -->
    <servlet-mapping>
        <servlet-name>BoardFrontController</servlet-name>
        <url-pattern>*.bo</url-pattern>
    </servlet-mapping>
    <resource-ref>
        <description>Connection</description>
        <res-ref-name>jdbc/OracleDB</res-ref-name>
        <res-type>javax.sql.DataSource</res-type>
        <res-auth>Container</res-auth>
    </resource-ref>
</web-app>





context.xml

<Context>
    <Resource
        name="jdbc/OracleDB"
        auth="Container"
        driverClassName="oracle.jdbc.driver.OracleDriver"
        type="javax.sql.DataSource"
        url="jdbc:oracle:thin:@localhost:1521:database"
        username="scott"
        password="tiger"
        maxActive="20"
        maxIdle="10"
        maxWait="-1" />
</Context>







- JAVA 파일



패키지 : net.board.action



Action.java

package net.board.action;

import javax.servlet.http.*;

public interface Action {
    public ActionForward execute(HttpServletRequest request,HttpServletResponse response) throws Exception;
}





ActionForward.java

package net.board.action;

public class ActionForward {
    private boolean isRedirect=false;
    private String path=null;

    public boolean isRedirect(){
        return isRedirect;
    }

    public String getPath(){
        return path;
    }

    public void setRedirect(boolean b){
        isRedirect=b;
    }

    public void setPath(String string){
        path=string;
    }
}





BoardFrontController.java

package net.board.action;

import java.io.IOException;

import javax.servlet.RequestDispatcher;
import javax.servlet.ServletException;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

 public class BoardFrontController
     extends javax.servlet.http.HttpServlet
     implements javax.servlet.Servlet {
     protected void doProcess(HttpServletRequest request, HttpServletResponse response)
         throws ServletException, IOException {
         System.out.println("¸Þ·Õ·Õ");

         String RequestURI=request.getRequestURI();
         String contextPath=request.getContextPath();
         String command=RequestURI.substring(contextPath.length());
         ActionForward forward=null;
         Action action=null;

           if(command.equals("/BoardList.bo")) {
               action = new BoardListAction();
               try{
                   forward=action.execute(request, response);
               }catch(Exception e){
                   e.printStackTrace();
               }
           }
         else if(command.equals("/BoardWrite.bo")){
               forward=new ActionForward();
               forward.setRedirect(false);
               forward.setPath("./board/qna_board_write.jsp");
           }else if(command.equals("/BoardReplyAction.bo")){
               action = new BoardReplyView();
               try{
                   forward=action.execute(request, response);
               }catch(Exception e){
                   e.printStackTrace();
               }
           }else if(command.equals("/BoardDelete.bo")){
               forward=new ActionForward();
               forward.setRedirect(false);
               forward.setPath("./board/qna_board_delete.jsp");
        }else if(command.equals("/BoardModify.bo")){
               action = new BoardModifyView();
               try{
                   forward=action.execute(request, response);
               }catch(Exception e){
                   e.printStackTrace();
               }
            }else if(command.equals("/BoardAddAction.bo")){
               action  = new BoardAddAction();
               try {
                   forward=action.execute(request, response );
               } catch (Exception e) {
                   e.printStackTrace();
               }
           }else if(command.equals("/BoardReplyView.bo")){
               action = new BoardReplyAction();
               try{
                   forward=action.execute(request, response);
               }catch(Exception e){
                   e.printStackTrace();
               }
           }else if(command.equals("/BoardModifyAction.bo")){
               action = new BoardModifyAction();
               try{
                   forward=action.execute(request, response);
               }catch(Exception e){
                   e.printStackTrace();
               }
           }else if(command.equals("/BoardDeleteAction.bo")){
               action = new BoardDeleteAction();
               try{
                   forward=action.execute(request, response);
               }catch(Exception e){
                   e.printStackTrace();
               }
           }else if(command.equals("/BoardList.bo")){
               action = new BoardListAction();
               try{
                   forward=action.execute(request, response);
               }catch(Exception e){
                   e.printStackTrace();
               }
           }else if(command.equals("/BoardDetailAction.bo")){
               action = new BoardDetailAction();
               try{
                   forward=action.execute(request, response);
               }catch(Exception e){
                   e.printStackTrace();
               }
           }

           if(forward.isRedirect()){
               response.sendRedirect(forward.getPath());
           }else{
               RequestDispatcher dispatcher=
                   request.getRequestDispatcher(forward.getPath());
               dispatcher.forward(request, response);
           }
     }
    protected void doGet(HttpServletRequest request, HttpServletResponse response)
        throws ServletException, IOException {
        doProcess(request,response);
    }

    protected void doPost(HttpServletRequest request, HttpServletResponse response)
        throws ServletException, IOException {
        doProcess(request,response);
    }
}





BoardListAction.java

package net.board.action;

import java.util.*;

import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

import net.board.db.BoardDAO;

 public class BoardListAction implements Action {
     public ActionForward execute(HttpServletRequest request,HttpServletResponse response) throws Exception{
        BoardDAO boarddao=new BoardDAO();
        List boardlist=new ArrayList();

          int page=1;
        int limit=10;

        if(request.getParameter("page")!=null){
            page=Integer.parseInt(request.getParameter("page"));
        }

        int listcount=boarddao.getListCount(); //총 리스트 수를 받아옴.
        boardlist = boarddao.getBoardList(page,limit); //리스트를 받아옴.

        //총 페이지 수.
           int maxpage=(int)((double)listcount/limit+0.95); //0.95를 더해서 올림 처리.
           //현재 페이지에 보여줄 시작 페이지 수(1, 11, 21 등...)
           int startpage = (((int) ((double)page / 10 + 0.9)) - 1) * 10 + 1;
           //현재 페이지에 보여줄 마지막 페이지 수.(10, 20, 30 등...)
           int endpage = maxpage;

           if (endpage>startpage+10-1) endpage=startpage+10-1;

           request.setAttribute("page", page);          //현재 페이지 수.
           request.setAttribute("maxpage", maxpage); //최대 페이지 수.
           request.setAttribute("startpage", startpage); //현재 페이지에 표시할 첫 페이지 수.
           request.setAttribute("endpage", endpage);     //현재 페이지에 표시할 끝 페이지 수.
        request.setAttribute("listcount",listcount); //글 수.
        request.setAttribute("boardlist", boardlist);

        ActionForward forward= new ActionForward();
           forward.setRedirect(false);
           forward.setPath("./board/qna_board_list.jsp");
           return forward;
     }
 }





BoardModifyAction.java

package net.board.action;

import java.io.PrintWriter;

import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

import net.board.db.*;

 public class BoardModifyAction implements Action {
     public ActionForward execute(HttpServletRequest request,HttpServletResponse response)
         throws Exception{
         request.setCharacterEncoding("euc-kr");
         ActionForward forward = new ActionForward();
         boolean result = false;

         int num=Integer.parseInt(request.getParameter("BOARD_NUM"));

         BoardDAO boarddao=new BoardDAO();
         BoardBean boarddata=new BoardBean();

         boolean usercheck=boarddao.isBoardWriter(num, request.getParameter("BOARD_PASS"));
         if(usercheck==false){
                   response.setContentType("text/html;charset=euc-kr");
                   PrintWriter out=response.getWriter();
                   out.println("<script>");
                   out.println("alert('수정할 권한이 없습니다.');");
                   out.println("location.href='./BoardList.bo';");
                   out.println("</script>");
                   out.close();
                   return null;
         }

         try{
             boarddata.setBOARD_NUM(num);
             boarddata.setBOARD_SUBJECT(request.getParameter("BOARD_SUBJECT"));
             boarddata.setBOARD_CONTENT(request.getParameter("BOARD_CONTENT"));

             result = boarddao.boardModify(boarddata);
             if(result==false){
                   System.out.println("게시판 수정 실패");
                   return null;
                }
                System.out.println("게시판 수정 완료");

                forward.setRedirect(true);
                forward.setPath("./BoardDetailAction.bo?num="+boarddata.getBOARD_NUM());
                return forward;
            }catch(Exception ex){
                   ex.printStackTrace();
         }

         return null;
     }
}





BoardModifyView.java

package net.board.action;

import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

import net.board.db.BoardDAO;
import net.board.db.BoardBean;

public class BoardModifyView implements Action {
     public ActionForward execute(HttpServletRequest request,HttpServletResponse response) throws Exception{
             ActionForward forward = new ActionForward();
             request.setCharacterEncoding("euc-kr");

            BoardDAO boarddao=new BoardDAO();
               BoardBean boarddata=new BoardBean();

            int num=Integer.parseInt(request.getParameter("num"));
               boarddata=boarddao.getDetail(num);

               if(boarddata==null){
                   System.out.println("(수정)상세보기 실패");
                   return null;
               }
               System.out.println("(수정)상세보기 성공");

               request.setAttribute("boarddata", boarddata);
               forward.setRedirect(false);
               forward.setPath("./board/qna_board_modify.jsp");
               return forward;
     }
}





BoardReplayAction.java

package net.board.action;

import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

import net.board.db.BoardDAO;
import net.board.db.BoardBean;

public class BoardReplyAction implements Action {
     public ActionForward execute(HttpServletRequest request,HttpServletResponse response)
     throws Exception{
             request.setCharacterEncoding("euc-kr");
             ActionForward forward = new ActionForward();

            BoardDAO boarddao=new BoardDAO();
               BoardBean boarddata=new BoardBean();
               int result=0;

               boarddata.setBOARD_NUM(Integer.parseInt(request.getParameter("BOARD_NUM")));
               boarddata.setBOARD_NAME(request.getParameter("BOARD_NAME"));
               boarddata.setBOARD_PASS(request.getParameter("BOARD_PASS"));
               boarddata.setBOARD_SUBJECT(request.getParameter("BOARD_SUBJECT"));
               boarddata.setBOARD_CONTENT(request.getParameter("BOARD_CONTENT"));
               boarddata.setBOARD_RE_REF(Integer.parseInt(request.getParameter("BOARD_RE_REF")));
               boarddata.setBOARD_RE_LEV(Integer.parseInt(request.getParameter("BOARD_RE_LEV")));
               boarddata.setBOARD_RE_SEQ(Integer.parseInt(request.getParameter("BOARD_RE_SEQ")));

               result=boarddao.boardReply(boarddata);
               if(result==0){
                   System.out.println("´äÀå ½ÇÆÐ");
                   return null;
               }
               System.out.println("´äÀå ¿Ï·á");

               forward.setRedirect(true);
               forward.setPath("./BoardDetailAction.bo?num="+result);
               return forward;
    }
}





BoardReplayView.java

package net.board.action;

import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

import net.board.db.BoardDAO;
import net.board.db.BoardBean;

public class BoardReplyView implements Action {
    public ActionForward execute(HttpServletRequest request, HttpServletResponse response) throws Exception {
        ActionForward forward = new ActionForward();

        BoardDAO boarddao = new BoardDAO();
        BoardBean boarddata = new BoardBean();

        int num = Integer.parseInt(request.getParameter("num"));

        boarddata = boarddao.getDetail(num);

        if (boarddata == null) {
            System.out.println("답장 페이지 이동 실패");
            return null;
        }
        System.out.println("답장 페이지 이동 완료");

        request.setAttribute("boarddata", boarddata);

        forward.setRedirect(false);
        forward.setPath("./board/qna_board_reply.jsp");
        return forward;
    }
}







패키지 : net.board.db



BoardBean.java

package net.board.db;

import java.sql.Date;

public class BoardBean {
    private int BOARD_NUM;
    private String BOARD_NAME;
    private String BOARD_PASS;
    private String BOARD_SUBJECT;
    private String BOARD_CONTENT;
    private String BOARD_FILE;
    private int BOARD_RE_REF;
    private int BOARD_RE_LEV;
    private int BOARD_RE_SEQ;
    private int BOARD_READCOUNT;
    private Date BOARD_DATE;

    public int getBOARD_NUM() {
        return BOARD_NUM;
    }
    public void setBOARD_NUM(int board_num) {
        BOARD_NUM = board_num;
    }
    public String getBOARD_NAME() {
        return BOARD_NAME;
    }
    public void setBOARD_NAME(String board_name) {
        BOARD_NAME = board_name;
    }
    public String getBOARD_PASS() {
        return BOARD_PASS;
    }
    public void setBOARD_PASS(String board_pass) {
        BOARD_PASS = board_pass;
    }
    public String getBOARD_SUBJECT() {
        return BOARD_SUBJECT;
    }
    public void setBOARD_SUBJECT(String board_subject) {
        BOARD_SUBJECT = board_subject;
    }
    public String getBOARD_CONTENT() {
        return BOARD_CONTENT;
    }
    public void setBOARD_CONTENT(String board_content) {
        BOARD_CONTENT = board_content;
    }
    public String getBOARD_FILE() {
        return BOARD_FILE;
    }
    public void setBOARD_FILE(String board_file) {
        BOARD_FILE = board_file;
    }
    public int getBOARD_RE_REF() {
        return BOARD_RE_REF;
    }
    public void setBOARD_RE_REF(int board_re_ref) {
        BOARD_RE_REF = board_re_ref;
    }
    public int getBOARD_RE_LEV() {
        return BOARD_RE_LEV;
    }
    public void setBOARD_RE_LEV(int board_re_lev) {
        BOARD_RE_LEV = board_re_lev;
    }
    public int getBOARD_RE_SEQ() {
        return BOARD_RE_SEQ;
    }
    public void setBOARD_RE_SEQ(int board_re_seq) {
        BOARD_RE_SEQ = board_re_seq;
    }
    public int getBOARD_READCOUNT() {
        return BOARD_READCOUNT;
    }
    public void setBOARD_READCOUNT(int board_readcount) {
        BOARD_READCOUNT = board_readcount;
    }
    public Date getBOARD_DATE() {
        return BOARD_DATE;
    }
    public void setBOARD_DATE(Date board_date) {
        BOARD_DATE = board_date;
    }
}





BoardDAO.java

package net.board.db;

import java.sql.Connection;
import java.sql.PreparedStatement;
import java.sql.ResultSet;
import java.sql.SQLException;
import java.util.ArrayList;
import java.util.List;

import javax.naming.Context;
import javax.naming.InitialContext;
import javax.sql.DataSource;

public class BoardDAO {
    Connection con;
    PreparedStatement pstmt;
    ResultSet rs;

    public BoardDAO() {
        try{
            Context init = new InitialContext();
              DataSource ds = (DataSource) init.lookup("java:comp/env/jdbc/OracleDB");
              con = ds.getConnection();
        }catch(Exception ex){
            System.out.println("DB 연결 실패 : " + ex);
            return;
        }
    }

    //글의 개수 구하기.
    public int getListCount() {
        int x= 0;

        try{
            pstmt=con.prepareStatement("select count(*) from board");
            rs = pstmt.executeQuery();

            if(rs.next()){
                x=rs.getInt(1);
            }
        }catch(Exception ex){
            System.out.println("getListCount 에러: " + ex);
        }finally{
            if(rs!=null) try{rs.close();}catch(SQLException ex){}
            if(pstmt!=null) try{pstmt.close();}catch(SQLException ex){}
        }
        return x;
    }

    //글 목록 보기.
    public List getBoardList(int page,int limit){
        String board_list_sql="select * from "+
        "(select rownum rnum,BOARD_NUM,BOARD_NAME,BOARD_SUBJECT,"+
        "BOARD_CONTENT,BOARD_FILE,BOARD_RE_REF,BOARD_RE_LEV,"+
        "BOARD_RE_SEQ,BOARD_READCOUNT,BOARD_DATE from "+
        "(select * from board order by BOARD_RE_REF desc,BOARD_RE_SEQ asc)) "+
        "where rnum>=? and rnum<=?";

        List list = new ArrayList();

        int startrow=(page-1)*10+1; //읽기 시작할 row 번호.
        int endrow=startrow+limit-1; //읽을 마지막 row 번호.
        try{
            pstmt = con.prepareStatement(board_list_sql);
            pstmt.setInt(1, startrow);
            pstmt.setInt(2, endrow);
            rs = pstmt.executeQuery();

            while(rs.next()){
                BoardBean board = new BoardBean();
                board.setBOARD_NUM(rs.getInt("BOARD_NUM"));
                board.setBOARD_NAME(rs.getString("BOARD_NAME"));
                board.setBOARD_SUBJECT(rs.getString("BOARD_SUBJECT"));
                board.setBOARD_CONTENT(rs.getString("BOARD_CONTENT"));
                board.setBOARD_FILE(rs.getString("BOARD_FILE"));
                board.setBOARD_RE_REF(rs.getInt("BOARD_RE_REF"));
                board.setBOARD_RE_LEV(rs.getInt("BOARD_RE_LEV"));
                board.setBOARD_RE_SEQ(rs.getInt("BOARD_RE_SEQ"));
                board.setBOARD_READCOUNT(rs.getInt("BOARD_READCOUNT"));
                board.setBOARD_DATE(rs.getDate("BOARD_DATE"));
                list.add(board);
            }

            return list;
        }catch(Exception ex){
            System.out.println("getBoardList 에러 : " + ex);
        }finally{
            if(rs!=null) try{rs.close();}catch(SQLException ex){}
            if(pstmt!=null) try{pstmt.close();}catch(SQLException ex){}
        }
        return null;
    }

    //글 내용 보기.
    public BoardBean getDetail(int num) throws Exception{
        BoardBean board = null;
        try{
            pstmt = con.prepareStatement(
                    "select * from board where BOARD_NUM = ?");
            pstmt.setInt(1, num);

            rs= pstmt.executeQuery();

            if(rs.next()){
                board = new BoardBean();
                board.setBOARD_NUM(rs.getInt("BOARD_NUM"));
                board.setBOARD_NAME(rs.getString("BOARD_NAME"));
                board.setBOARD_SUBJECT(rs.getString("BOARD_SUBJECT"));
                board.setBOARD_CONTENT(rs.getString("BOARD_CONTENT"));
                board.setBOARD_FILE(rs.getString("BOARD_FILE"));
                board.setBOARD_RE_REF(rs.getInt("BOARD_RE_REF"));
                board.setBOARD_RE_LEV(rs.getInt("BOARD_RE_LEV"));
                board.setBOARD_RE_SEQ(rs.getInt("BOARD_RE_SEQ"));
                board.setBOARD_READCOUNT(rs.getInt("BOARD_READCOUNT"));
                board.setBOARD_DATE(rs.getDate("BOARD_DATE"));
            }
            return board;
        }catch(Exception ex){
            System.out.println("getDetail 에러 : " + ex);
        }finally{
            if(rs!=null)try{rs.close();}catch(SQLException ex){}
            if(pstmt !=null)try{pstmt.close();}catch(SQLException ex){}
        }
        return null;
    }

    //글 등록.
    public boolean boardInsert(BoardBean board){
        int num =0;
        String sql="";

        int result=0;

        try{
            pstmt=con.prepareStatement("select max(board_num) from board");
            rs = pstmt.executeQuery();

            if(rs.next())
                num =rs.getInt(1)+1;
            else
                num=1;

            sql="insert into board (BOARD_NUM,BOARD_NAME,BOARD_PASS,BOARD_SUBJECT,";
            sql+="BOARD_CONTENT, BOARD_FILE, BOARD_RE_REF,"+
                "BOARD_RE_LEV,BOARD_RE_SEQ,BOARD_READCOUNT,"+
                "BOARD_DATE) values(?,?,?,?,?,?,?,?,?,?,sysdate)";

            pstmt = con.prepareStatement(sql);
            pstmt.setInt(1, num);
            pstmt.setString(2, board.getBOARD_NAME());
            pstmt.setString(3, board.getBOARD_PASS());
            pstmt.setString(4, board.getBOARD_SUBJECT());
            pstmt.setString(5, board.getBOARD_CONTENT());
            pstmt.setString(6, board.getBOARD_FILE());
            pstmt.setInt(7, num);
            pstmt.setInt(8, 0);
            pstmt.setInt(9, 0);
            pstmt.setInt(10, 0);

            result=pstmt.executeUpdate();
            if(result==0)return false;

            return true;
        }catch(Exception ex){
            System.out.println("boardInsert 에러 : "+ex);
        }finally{
            if(rs!=null) try{rs.close();}catch(SQLException ex){}
            if(pstmt!=null) try{pstmt.close();}catch(SQLException ex){}
        }
        return false;
    }

    //글 답변.
    public int boardReply(BoardBean board){
        String board_max_sql="select max(board_num) from board";
        String sql="";
        int num=0;
        int result=0;

        int re_ref=board.getBOARD_RE_REF();
        int re_lev=board.getBOARD_RE_LEV();
        int re_seq=board.getBOARD_RE_SEQ();

        try{
            pstmt=con.prepareStatement(board_max_sql);
            rs = pstmt.executeQuery();
            if(rs.next())num =rs.getInt(1)+1;
            else num=1;

            sql="update board set BOARD_RE_SEQ=BOARD_RE_SEQ+1 where BOARD_RE_REF=? ";
            sql+="and BOARD_RE_SEQ>?";

            pstmt = con.prepareStatement(sql);
            pstmt.setInt(1,re_ref);
            pstmt.setInt(2,re_seq);
            result=pstmt.executeUpdate();

            re_seq = re_seq + 1;
            re_lev = re_lev+1;

            sql="insert into board (BOARD_NUM,BOARD_NAME,BOARD_PASS,BOARD_SUBJECT,";
            sql+="BOARD_CONTENT, BOARD_FILE,BOARD_RE_REF,BOARD_RE_LEV,BOARD_RE_SEQ,";
            sql+="BOARD_READCOUNT,BOARD_DATE) values(?,?,?,?,?,?,?,?,?,?,sysdate)";

            pstmt = con.prepareStatement(sql);
            pstmt.setInt(1, num);
            pstmt.setString(2, board.getBOARD_NAME());
            pstmt.setString(3, board.getBOARD_PASS());
            pstmt.setString(4, board.getBOARD_SUBJECT());
            pstmt.setString(5, board.getBOARD_CONTENT());
            pstmt.setString(6, ""); //답장에는 파일을 업로드하지 않음.
            pstmt.setInt(7, re_ref);
            pstmt.setInt(8, re_lev);
            pstmt.setInt(9, re_seq);
            pstmt.setInt(10, 0);
            pstmt.executeUpdate();
            return num;
        }catch(SQLException ex){
            System.out.println("boardReply 에러 : "+ex);
        }finally{
            if(rs!=null)try{rs.close();}catch(SQLException ex){}
            if(pstmt!=null)try{pstmt.close();}catch(SQLException ex){}
        }
        return 0;
    }

    //글 수정.
    public boolean boardModify(BoardBean modifyboard) throws Exception{
        String sql="update board set BOARD_SUBJECT=?,BOARD_CONTENT=? where BOARD_NUM=?";

        try{
            pstmt = con.prepareStatement(sql);
            pstmt.setString(1, modifyboard.getBOARD_SUBJECT());
            pstmt.setString(2, modifyboard.getBOARD_CONTENT());
            pstmt.setInt(3, modifyboard.getBOARD_NUM());
            pstmt.executeUpdate();
            return true;
        }catch(Exception ex){
            System.out.println("boardModify 에러 : " + ex);
        }finally{
            if(rs!=null)try{rs.close();}catch(SQLException ex){}
            if(pstmt!=null)try{pstmt.close();}catch(SQLException ex){}
            }
        return false;
    }

    //글 삭제.
    public boolean boardDelete(int num){
        String board_delete_sql="delete from board where BOARD_num=?";

        int result=0;

        try{
            pstmt=con.prepareStatement(board_delete_sql);
            pstmt.setInt(1, num);
            result=pstmt.executeUpdate();
            if(result==0)return false;

            return true;
        }catch(Exception ex){
            System.out.println("boardDelete 에러 : "+ex);
        }finally{
            try{
                if(pstmt!=null)pstmt.close();
            }catch(Exception ex) {}
        }

        return false;
    }

    //조회수 업데이트.
    public void setReadCountUpdate(int num) throws Exception{
        String sql="update board set BOARD_READCOUNT = "+
            "BOARD_READCOUNT+1 where BOARD_NUM = "+num;

        try{
            pstmt=con.prepareStatement(sql);
            pstmt.executeUpdate();
        }catch(SQLException ex){
            System.out.println("setReadCountUpdate 에러 : "+ex);
        }
    }

    //글쓴이인지 확인.
    public boolean isBoardWriter(int num,String pass){
        String board_sql="select * from board where BOARD_NUM=?";

        try{
            pstmt=con.prepareStatement(board_sql);
            pstmt.setInt(1, num);
            rs=pstmt.executeQuery();
            rs.next();

            if(pass.equals(rs.getString("BOARD_PASS"))){
                return true;
            }
        }catch(SQLException ex){
            System.out.println("isBoardWriter 에러 : "+ex);
        }
        return false;
    }

}







- JSP 파일



index.jsp

<%@ page language="java" contentType="text/html; charset=EUC-KR"
    pageEncoding="EUC-KR"%>

<!DOCTYPE html PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN" "http://www.w3.org/TR/html4/loose.dtd">
<html>
<head>
<meta http-equiv="Content-Type" content="text/html; charset=EUC-KR">
<title>Insert title here</title>
</head>
<body>
 <jsp:forward page="BoardList.bo"/>
</body>
</html>



qna_board_list.jsp

<%@ page language="java" contentType="text/html; charset=EUC-KR"%>
<%@ page import="java.util.*"%>
<%@ page import="java.text.SimpleDateFormat"%>
<%@ page import="net.board.db.*"%>

<%
    List boardList = (List) request.getAttribute("boardlist");
    int listcount = ((Integer) request.getAttribute("listcount")).intValue();
    int nowpage = ((Integer) request.getAttribute("page")).intValue();
    int maxpage = ((Integer) request.getAttribute("maxpage")).intValue();
    int startpage = ((Integer) request.getAttribute("startpage")).intValue();
    int endpage = ((Integer) request.getAttribute("endpage")).intValue();
%>

<html>
<head>
<title>MVC 게시판</title>
</head>

<body>
    <!-- 게시판 리스트 -->
    <table width=50% border="0" cellpadding="0" cellspacing="0">
        <tr align="center" valign="middle">
            <td colspan="4">MVC 게시판</td>
            <td align=right><font size=2>글 개수 : ${listcount }</font></td>
        </tr>

        <tr align="center" valign="middle" bordercolor="#333333">
            <td style="font-family: Tahoma; font-size: 8pt;" width="8%"
                height="26">
                <div align="center">번호</div>
            </td>
            <td style="font-family: Tahoma; font-size: 8pt;" width="50%">
                <div align="center">제목</div>
            </td>
            <td style="font-family: Tahoma; font-size: 8pt;" width="14%">
                <div align="center">작성자</div>
            </td>
            <td style="font-family: Tahoma; font-size: 8pt;" width="17%">
                <div align="center">날짜</div>
            </td>
            <td style="font-family: Tahoma; font-size: 8pt;" width="11%">
                <div align="center">조회수</div>
            </td>
        </tr>

        <%
            for (int i = 0; i < boardList.size(); i++) {
                BoardBean bl = (BoardBean) boardList.get(i);
        %>
        <tr align="center" valign="middle" bordercolor="#333333"
            onmouseover="this.style.backgroundColor='F8F8F8'"
            onmouseout="this.style.backgroundColor=''">
            <td height="23" style="font-family: Tahoma; font-size: 10pt;"><%=bl.getBOARD_NUM()%>
            </td>

            <td style="font-family: Tahoma; font-size: 10pt;">
                <div align="left">
                    <%
                        if (bl.getBOARD_RE_LEV() != 0) {
                    %>
                    <%
                        for (int a = 0; a <= bl.getBOARD_RE_LEV() * 2; a++) {
                    %>
                    &nbsp;
                    <%
                        }
                    %>
                    ▶
                    <%
                        } else {
                    %>
                    ▶
                    <%
                        }
                    %>
                    <a href="./BoardDetailAction.bo?num=<%=bl.getBOARD_NUM()%>"> <%=bl.getBOARD_SUBJECT()%>
                    </a>
                </div>
            </td>

            <td style="font-family: Tahoma; font-size: 10pt;">
                <div align="center"><%=bl.getBOARD_NAME()%></div>
            </td>
            <td style="font-family: Tahoma; font-size: 10pt;">
                <div align="center"><%=bl.getBOARD_DATE()%></div>
            </td>
            <td style="font-family: Tahoma; font-size: 10pt;">
                <div align="center"><%=bl.getBOARD_READCOUNT()%></div>
            </td>
        </tr>
        <%
            }
        %>
        <tr align=center height=20>
            <td colspan=7 style="font-family: Tahoma; font-size: 10pt;">
                <%
                    if (nowpage <= 1) {
                %> [이전]&nbsp; <%
     } else {
 %> <a href="./BoardList.bo?page=<%=nowpage - 1%>">[이전]</a>&nbsp; <%
     }
 %> <%
     for (int a = startpage; a <= endpage; a++) {
         if (a == nowpage) {
 %> [<%=a%>] <%
     } else {
 %> <a href="./BoardList.bo?page=<%=a%>">[<%=a%>]
            </a>&nbsp; <%
     }
 %> <%
     }
 %> <%
     if (nowpage >= maxpage) {
 %> [다음] <%
     } else {
 %> <a href="./BoardList.bo?page=<%=nowpage + 1%>">[다음]</a> <%
     }
 %>
            </td>
        </tr>
        <tr align="right">
            <td colspan="5"><a href="./BoardWrite.bo">[글쓰기]</a></td>
        </tr>
    </table>
</body>
</html>





qna_board_delete.jsp

<%@ page language="java" contentType="text/html; charset=EUC-KR"%>
<%
    int num=Integer.parseInt(request.getParameter("num"));
%>
<html>
<head>
<title>MVC 게시판</title>
</head>
<body>
<form name="deleteForm" action="./BoardDeleteAction.bo?num=<%=num %>"
    method="post">
<table border=1>
<tr>
    <td>
        <font size=2>글 비밀번호 : </font>
    </td>
    <td>
        <input name="BOARD_PASS" type="password">
    </td>
</tr>
<tr>
    <td colspan=2 align=center>
        <a href="javascript:deleteForm.submit()">삭제</a>
        &nbsp;&nbsp;
        <a href="javascript:history.go(-1)">돌아가기</a>
    </td>
</tr>
</table>
</form>
</body>
</html>





qna_board_modify.jsp

<%@ page language="java" contentType="text/html; charset=EUC-KR"%>
<%@ page import="net.board.db.*" %>
<%
    BoardBean board = (BoardBean)request.getAttribute("boarddata");
%>

<html>
<head>
    <title>MVC 게시판</title>
    <script type="text/javascript">
    function modifyboard(){
        modifyform.submit();
    }
    </script>
</head>

<body>
<!-- 게시판 수정 -->
<form action="BoardModifyAction.bo" method="post" name="modifyform">
<input type="hidden" name="BOARD_NUM" value=<%=board.getBOARD_NUM() %>>
<table cellpadding="0" cellspacing="0">
    <tr align="center" valign="middle">
        <td colspan="5">MVC 게시판</td>
    </tr>
    <tr>
        <td height="16" style="font-family:돋음; font-size:12">
            <div align="center">제 목</div>
        </td>
        <td>
            <input name="BOARD_SUBJECT" size="50" maxlength="100"
                value="<%=board.getBOARD_SUBJECT()%>">
        </td>
    </tr>
    <tr>
        <td style="font-family:돋음; font-size:12">
            <div align="center">내 용</div>
        </td>
        <td>
            <textarea name="BOARD_CONTENT" cols="67" rows="15">
            <%=board.getBOARD_CONTENT() %>
            </textarea>
        </td>
    </tr>
    <%if(!(board.getBOARD_FILE()==null)){ %>
    <tr>
        <td style="font-family:돋음; font-size:12">
            <div align="center">파일 첨부</div>
        </td>
        <td>
            &nbsp;&nbsp;<%=board.getBOARD_FILE() %>
        </td>
    </tr>
    <%} %>
    <tr>
        <td height="16" style="font-family:돋음; font-size:12">
            <div align="center">비밀번호</div>
        </td>
        <td>
            <input name="BOARD_PASS" type="password">
        </td>
    </tr>

    <tr bgcolor="cccccc">
        <td colspan="2" style="height:1px;">
        </td>
    </tr>
    <tr><td colspan="2">&nbsp;</td></tr>

    <tr align="center" valign="middle">
        <td colspan="5">
            <font size=2>
            <a href="javascript:modifyboard()">[수정]</a>&nbsp;&nbsp;
            <a href="javascript:history.go(-1)">[뒤로]</a>&nbsp;&nbsp;
            </font>
        </td>
    </tr>
</table>
</form>
<!-- 게시판 수정 -->
</body>
</html>
</html>





qna_board_replay.jsp

<%@ page language="java" contentType="text/html; charset=EUC-KR"%>
<%@ page import="net.board.db.*" %>
<%
    BoardBean board=(BoardBean)request.getAttribute("boarddata");
%>

<html>
<head>
    <title>MVC 게시판</title>
    <script language="javascript">
    function replyboard(){
        boardform.submit();
    }
    </script>
</head>
<body>
<!-- 게시판 답변 -->
<form action="./BoardReplyView.bo" method="post" name="boardform">
<input type="hidden" name="BOARD_NUM" value="<%=board.getBOARD_NUM() %>">
<input type="hidden" name="BOARD_RE_REF" value="<%=board.getBOARD_RE_REF() %>">
<input type="hidden" name="BOARD_RE_LEV" value="<%=board.getBOARD_RE_LEV() %>">
<input type="hidden" name="BOARD_RE_SEQ" value="<%=board.getBOARD_RE_SEQ() %>">

<table cellpadding="0" cellspacing="0">
    <tr align="center" valign="middle">
        <td colspan="5">MVC 게시판</td>
    </tr>
    <tr>
        <td style="font-family:돋음; font-size:12" height="16">
            <div align="center">글쓴이</div>
        </td>
        <td>
            <input name="BOARD_NAME" type="text"/>
        </td>
    </tr>
    <tr>
        <td style="font-family:돋음; font-size:12" height="16">
            <div align="center">제 목</div>
        </td>
        <td>
            <input name="BOARD_SUBJECT" type="text" size="50"
                maxlength="100" value="Re: <%=board.getBOARD_SUBJECT() %>"/>
        </td>
    </tr>
    <tr>
        <td style="font-family:돋음; font-size:12">
            <div align="center">내 용</div>
        </td>
        <td>
            <textarea name="BOARD_CONTENT" cols="67" rows="15"></textarea>
        </td>
    </tr>
    <tr>
        <td style="font-family:돋음; font-size:12">
            <div align="center">비밀번호</div>
        </td>
        <td>
            <input name="BOARD_PASS" type="password">
        </td>
    </tr>

    <tr bgcolor="cccccc">
        <td colspan="2" style="height:1px;">
        </td>
    </tr>
    <tr><td colspan="2">&nbsp;</td></tr>

    <tr align="center" valign="middle">
        <td colspan="5">
        <a href="javascript:replyboard()">[등록]</a>&nbsp;&nbsp;
        <a href="javascript:history.go(-1)">[뒤로]</a>
        </td>
    </tr>
</table>
</form>
<!-- 게시판 답변 -->
</body>
</html>





qna_board_view.jsp

<%@ page language="java" contentType="text/html; charset=EUC-KR"%>
<%@ page import="net.board.db.*" %>
<%
    BoardBean board = (BoardBean)request.getAttribute("boarddata");
%>

<html>
<head>
    <title>MVC 게시판</title>
</head>

<body>
<!-- 게시판 수정 -->
<table cellpadding="0" cellspacing="0">
    <tr align="center" valign="middle">
        <td colspan="5">MVC 게시판</td>
    </tr>

    <tr>
        <td style="font-family:돋음; font-size:12" height="16">
            <div align="center">제 목&nbsp;&nbsp;</div>
        </td>

        <td style="font-family:돋음; font-size:12">
        <%=board.getBOARD_SUBJECT()%>
        </td>
    </tr>

    <tr bgcolor="cccccc">
        <td colspan="2" style="height:1px;">
        </td>
    </tr>

    <tr>
        <td style="font-family:돋음; font-size:12">
            <div align="center">내 용</div>
        </td>
        <td style="font-family:돋음; font-size:12">
            <table border=0 width=490 height=250 style="table-layout:fixed">
                <tr>
                    <td valign=top style="font-family:돋음; font-size:12">
                    <%=board.getBOARD_CONTENT() %>
                    </td>
                </tr>
            </table>
        </td>
    </tr>
    <tr>
        <td style="font-family:돋음; font-size:12">
            <div align="center">첨부파일</div>
        </td>
        <td style="font-family:돋음; font-size:12">
        <%if(!(board.getBOARD_FILE()==null)){ %>
        <a href="./boardupload/<%=board.getBOARD_FILE()%>">
            <%=board.getBOARD_FILE() %>
        </a>
        <%} %>
        </td>
    </tr>

    <tr bgcolor="cccccc">
        <td colspan="2" style="height:1px;"></td>
    </tr>
    <tr><td colspan="2">&nbsp;</td></tr>

    <tr align="center" valign="middle">
        <td colspan="5">
            <font size=2>
            <a href="./BoardReplyAction.bo?num=<%=board.getBOARD_NUM() %>">
            [답변]
            </a>&nbsp;&nbsp;
            <a href="./BoardModify.bo?num=<%=board.getBOARD_NUM() %>">
            [수정]
            </a>&nbsp;&nbsp;
            <a href="./BoardDelete.bo?num=<%=board.getBOARD_NUM() %>">
            [삭제]
            </a>&nbsp;&nbsp;
            <a href="./BoardList.bo">[목록]</a>&nbsp;&nbsp;
            </font>
        </td>
    </tr>
</table>
<!-- 게시판 수정 -->
</body>
</html>





qna_board_write.jsp

<%@ page language="java" contentType="text/html; charset=EUC-KR"%>

<html>
<head>
    <title>MVC 게시판</title>
    <script language="javascript">
    function addboard(){
        boardform.submit();
    }
    </script>
</head>
<body>
<!-- 게시판 등록 -->
<form action="./BoardAddAction.bo" method="post"
    enctype="multipart/form-data" name="boardform">
<table cellpadding="0" cellspacing="0">
    <tr align="center" valign="middle">
        <td colspan="5">MVC 게시판</td>
    </tr>
    <tr>
        <td style="font-family:돋음; font-size:12" height="16">
            <div align="center">글쓴이</div>
        </td>
        <td>
            <input name="BOARD_NAME" type="text" size="10" maxlength="10"
                value=""/>
        </td>
    </tr>
    <tr>
        <td style="font-family:돋음; font-size:12" height="16">
            <div align="center">비밀번호</div>
        </td>
        <td>
            <input name="BOARD_PASS" type="password" size="10" maxlength="10"
                value=""/>
        </td>
    </tr>
    <tr>
        <td style="font-family:돋음; font-size:12" height="16">
            <div align="center">제 목</div>
        </td>
        <td>
            <input name="BOARD_SUBJECT" type="text" size="50" maxlength="100"
                value=""/>
        </td>
    </tr>
    <tr>
        <td style="font-family:돋음; font-size:12">
            <div align="center">내 용</div>
        </td>
        <td>
            <textarea name="BOARD_CONTENT" cols="67" rows="15"></textarea>
        </td>
    </tr>
    <tr>
        <td style="font-family:돋음; font-size:12">
            <div align="center">파일 첨부</div>
        </td>
        <td>
            <input name="BOARD_FILE" type="file"/>
        </td>
    </tr>
    <tr bgcolor="cccccc">
        <td colspan="2" style="height:1px;">
        </td>
    </tr>
    <tr><td colspan="2">&nbsp;</td></tr>
    <tr align="center" valign="middle">
        <td colspan="5">
            <a href="javascript:addboard()">[등록]</a>&nbsp;&nbsp;
            <a href="javascript:history.go(-1)">[뒤로]</a>
        </td>
    </tr>
</table>
</form>
<!-- 게시판 등록 -->
</body>
</html>
